3 AXLE BOMB-CART TRAILER+COIL WELL BED
Suitable for containers application within the port. Both tandem and tridem axle versions.
Payload Capacity
26.83T
Unladen weight of trailer
7.4T
Gross Laden weight of trailer
40.20T
Overall length of trailer
+/-10mm
Overall width of trailer
+/-10mm
Unladen height of trailer at rear
1600 +/-25mm
Landing Leg
Two speed landing leg shall be provided at the front end.
King Pin
2” king pin equivalent to IS : 6763 Part I provided.
Wheel Rim:
7.50 x 20. MAKE-WHEELS INDIA / KALYANI / AL.
Tyre:
10.00 x 20 - 16 PR. MAKE-JK/CEAT/APOLLO/MICHELIN/CONTINENTAL.
Painting:
One coat of primer and one coat of finish PU paint with colour of customer choice.
Surface Preparation:
Surface shall be cleaned by shot blasting followed by painting which confirms ASTM B117.2011.
Other Fitments:
Fitments such SUPD, RUPD, TOOL BOX, reflectors on both sides and rear shall be provided as per CMVR.
Suspension:
13T/15T/16T/18T capacity leaf spring suspension with load equalizing brackets. MAKE-YORK/JOST/BPW/FUWA/AAT.
Axles:
13T/16T/18T Axle shall be provided. MAKE-YORK/JOST/BPW/FUWA/AL/TATA.
Electrical:
24 V DC electrical include tail lamp, brake lamp and direction Indicator lamps fitted at rear end of trailer. Side marker lamps shall be provided on both sides.
Brakes:
Wabco twin line ABS air brake system coupled to tractor brake system. Trailer brakes are actuated from tractor. T24 brake chamber shall be provided on all axles. Parking brake shall
be pneumatically actuated.
Chassis:
All steel welded construction. 2 nos Main longitudinal members are high strength, lighter weight, Parallel flange Beam of IS-2062 (or) Equivalent grade steel running along full length of the trailer. Cross members - Rolled or Folded of material IS-2062/ST-52 are positioned at suitable locations. 6 nos of shock absorber spring provided for 20ft and 40ft container.
